15x15 - 3D BEND

Product range
PowerVoltageCCTCRILED densityIP ratingPCB widthCut length
10W/m24V DC3000K90120 LED/mIP6710mm50mm
10W/m24V DC4000K90120 LED/mIP6710mm50mm
Technical specifications

Light source & performance

LED typeSMD 2835
Beam angle120°
Light output400 - 500 lm/m
Lighting effectUniform dot-free illumination
Color consistencyStandard SDCM

Electrical specifications

Input voltage24V DC
Current consumption417 mA/m
Maximum run length5 meters
Power feedingSingle-side power feed
Dimming compatibilitySupported depending on control system

Mechanical specifications

Product size15 x 15 mm
FPC width10 mm
Cuttable length50mm
MaterialExtruded silicone
Bend type3D Bend
Bending directionTop bend & side bend
Minimum bend radius300 mm
Cable exit optionsEnd / side / bottom
Installation methodClips / aluminum profiles

Protection & environment

IP ratingIP67
Impact protectionIK08
Working temperature-25°C to +60°C
Storage temperature-25°C to +70°C
UV resistance✓
Flame resistance✓
Saltwater resistance✓
Solvent resistance✓

Description

Architectural 3D bending neon flex designed for continuous linear illumination in free-form and customized lighting applications. The flexible silicone construction enables both top and side bending directions while maintaining uniform dot-free lighting performance for creative architectural and decorative installations.

Applications

• Architectural lighting
• Decorative linear lighting
• Curved lighting features
• Hospitality projects
• Furniture integration
• Customized lighting applications

Key Feature

  • • Uniform

    dot-free illumination

  • • Flexible

    3D-bending design

  • • Silicone anti-yellowing

    construction

  • • IP67

    outdoor protection

  • • Compatible with

    clips and profile installation

  • • Top and side

    bending capability

WARRANTY

5 Years Warranty

CERTIFICATIONS

Neon Flex 12x12mm certifications
