Input Voltage
DC24V
LED Type
COB
CRI
Ra90
Beam Angle
180°
IP Rating
IP67
Working Temperature
-25°C to +60°C
Warranty
5 Years
| STRP-COB5W | STRP-COB10W | STRP-COB14W | |
|---|---|---|---|
| Power | 5W/M | 10W/M | 14W/M |
| Current | 208 mA/M | 416 mA/M | 583 mA/M |
| Chips/m | 320 | 480 | 512 |
| Lumens | 400 lm/M | 800 lm/M | 1150 lm/M |
STRP-COB5W
Power5W/M
Current208 mA/M
Chips/m320
Lumens400 lm/M
STRP-COB10W
Power10W/M
Current416 mA/M
Chips/m480
Lumens800 lm/M
STRP-COB14W
Power14W/M
Current583 mA/M
Chips/m512
Lumens1150 lm/M
Dimension(unit: mm):
Description
Waterproof COB LED strip delivering continuous, dot-free illumination for linear decorative and architectural lighting applications.
Ideal Applications
• Cove lighting
• Retail and mall lighting
• Cabinet lighting
• Hospitality applications
• Architectural linear lighting
